Characteristics
1. Reversing Method is that grabs the top and bottom of the book and reverse to 180 degrees. You can choose the reversing mode to diverse types, which make the unit reverse every 1st, 2nd, 4th unit or reverse 2nd unit , ignore 3rd one and reverse whole units, etc.
2. The entrance of the stacking part takes unique type(P.T), which makes supply to stacking part secure
3. The ejecting equipment (P.T) is attached on the outlet of the stacking part.
Features
1. Book size: MIN A6(105¡¿148) MAX B4(257¡¿364)
2. Stacking height: MAX 400m/m
3. Stacking Capacity: MAX 50 Unit/min
4. Output Capacity: MAX 25 book/min
5. Changing Method: every 2 units, reversing 2 units ; Ignoring 3rd unit, reversing others
6. Electric Power: 3 Phase 200V, 1kw
7. Air Required: Approx.1.5kw (160N§¤/min)
8. Machine Size: 980W¡¿2425L¡¿1500H
9. Machine Weight: 1000kg |
